Plan a Clear Layout on a Limited Metal Surface

A successful layout gives the most important information enough space and contrast. A logo, event name, date and decorative border may all fit in a digital drawing, but they may compete once placed on a compact metal shape. Design articles in this group examine visual hierarchy, edge clearance, balance and the relationship between the outer shape and internal details.

Front and reverse views should have separate jobs. A medal front might carry the event identity, while the reverse holds a date, distance or sponsor message. A challenge coin can support two coordinated faces, but each face still needs a clear focal point. A small lapel pin often requires a simpler information hierarchy than a plaque or assembled trophy.

• Identify the primary mark or message before adding supporting details.
• Keep borders, openings and component edges visible in the artwork.
• Separate front, reverse and side-specific instructions.
• Check that repeated versions use the same logo proportions and visual rules.
• Show where decorative elements may end and functional areas begin.

Product shape and construction affect the available design area. Buyers who have not selected a format can compare the main options through the custom metal products hub before finalizing a layout.

Translate Flat Graphics into Raised and Recessed Metal

Relief artwork describes which parts of a design sit above or below the surrounding surface. Raised metal can define a portrait, emblem, border or line of text. Recessed areas can create background separation or receive color. Sculpted relief uses changing surface levels to give a subject a more dimensional form.

Articles on dimensional artwork focus on feature hierarchy, foreground and background separation, viewing angle and reference quality. A flat logo may be clear with simple raised and recessed levels. A face, building or layered scene may need 3D development so the intended form can be reviewed before mold work.

Reference images should show the features that matter, not just the general subject. Front, angled and side views can help explain depth where one image leaves the shape unclear. Notes should also distinguish a true dimensional feature from a printed shadow or gradient.

Gairun uses CNC mold engraving, die-casting, stamping and hydraulic high-relief processes where suitable. These processes are mentioned in design articles only to explain why relief decisions matter. Detailed process selection belongs in the manufacturing guidance, and the final route depends on an engineering review of the product and artwork.

Separate Enamel Colors and Printed Graphics

Color preparation depends on how the graphic will be reproduced. Soft enamel and imitation hard enamel use defined color areas, often divided by metal borders. Screen printing and UV printing can handle graphic details that do not follow the same raised-metal structure. Clear epoxy may be considered as a separate surface treatment over decorated areas.

For enamel artwork, each color zone should be easy to identify. Very small isolated areas, narrow gaps and unclear boundaries require review because the product size and forming route affect feasibility. Spot-color references can communicate the intended color direction, but they do not replace a review of the metal base, plating and production method.

Gradients, photographic effects and details that cannot be divided into enamel cells may point toward a printed treatment. The choice is not only about appearance. It changes how the artwork should identify boundaries, visible metal and layered graphic elements.

Use the soft enamel and imitation hard enamel comparison when choosing between recessed and smooth enamel surfaces. For broader process information, consult the relevant fixed resource rather than relying on a design article as a production specification.

Protect Text, Logos and Fine Graphic Details

Small text and detailed logos often cause approval problems because the original artwork was made for a screen, package or large sign. Custom metal product design articles in this group examine how to simplify fine features without changing the identity of the mark.

Text should be checked for spelling, capitalization and version accuracy before approval. Font names or outlined letterforms help prevent unexpected substitutions. Outlining converts editable text into fixed graphic shapes, but the resulting forms still need to be assessed at the planned product size.

Logo files should preserve the correct proportions and show which elements are essential. Do not rebuild a protected mark from a low-quality reference if an original file is available. Buyers and agencies should also confirm that they have permission to reproduce submitted names, logos, emblems and other protected artwork.

There is no single detail rule that applies to every medal, coin or pin. Feasibility depends on product dimensions, material, forming route, relief structure, finish and color treatment. Technical review should therefore examine the complete design rather than one isolated line or letter.

Show Attachments, Moving Parts and Separate Components

Artwork for a multi-part product must explain how the pieces relate. A medal ribbon, pin attachment, keyring, bottle-opener feature, rotating center or combined award component can affect orientation, spacing and the usable design area.

Articles in this group show how to mark connection points, movement boundaries and front-to-reverse alignment. A spinning medal, for example, needs separate artwork for the fixed body and rotating center. The drawing should make clear which side faces forward, where the rotation occurs and which graphics belong to each component.

• Provide separate views for each component.
• Label the intended front, reverse and orientation.
• Mark holes, loops, posts or other connection locations.
• Keep functional edges distinct from decorative artwork.
• Show the permitted movement area for a rotating or linked part.
• Identify repeated components that use different graphics or finishes.

These notes support review but do not confirm mechanical feasibility. Gairun assesses attachments, moving structures and component interfaces through its artwork design and proofing and engineering workflow.

Prepare Files for a More Precise Technical Review

A production-ready artwork package gives the reviewer enough information to understand the intended product without guessing. Vector artwork is useful because shapes, lines and color areas can be inspected and adjusted. A usable PDF may also provide clear geometry and dimensions. Hand-drawn concepts can start the discussion when finished digital artwork is not available.

More complete inputs support a more precise assessment. Include the product family, intended dimensions, front and reverse views, color references, relief notes, finish callouts and separate component drawings where relevant. Keep file versions clearly identified so comments are applied to the correct design.

1. Confirm the overall shape and main dimensions.
2. Separate front, reverse and component views.
3. Identify raised, recessed, sculpted and printed details.
4. Mark enamel colors, visible metal and finish areas.
5. Provide editable logo or text artwork when available.
6. Add attachment, orientation and assembly notes.
7. Review spelling, dates and design-version details.

Gairun can develop 2D or 3D artwork from vector files, PDFs and sketches when further design support is needed. Acceptance as a starting material does not mean a file is ready for tooling. The design must first be reviewed against the selected product structure and process.

Apply the Advice to the Right Product Family

The same graphic can require different treatment when moved from one product to another. A design planned for a large medal may need a simpler hierarchy on a lapel pin. A two-sided challenge coin offers different content options from a plaque with several assembled elements.

• Custom medals: Consider the event message, front and reverse hierarchy, ribbon connection and any rotating or combined parts.
• Challenge coins: Coordinate two faces, relief levels, edge presentation, color areas and metal surface contrast.
• Lapel pins and badges: Match fine details and color boundaries to enamel, formed metal or printed artwork.
• Metal trophies and plaques: Map logos, names and award messages across the metal body and any separate wood or crystal components.
• Keychains and bottle openers: Keep brand artwork clear of connection points, keyrings and functional opener edges.

Use the main product pages to compare physical formats and decoration options. Return to the design articles once you know where the artwork will be applied.

Common Questions About Custom Metal Artwork

What information should custom metal product artwork include before technical review?

Include the product type, overall dimensions, front and reverse graphics, intended colors, relief direction, finish notes and attachment details. Multi-part products also need separate component views and orientation notes. The reviewer may request more information after assessing the design.

When should a design use raised and recessed metal instead of printed detail?

Raised and recessed metal suits graphics that depend on physical depth, metal borders or a formed surface. Printing may suit gradients, very detailed graphics or effects that are not divided into metal and enamel areas. The product size and intended appearance should guide the choice.

How should colors be separated for soft enamel or imitation hard enamel?

Show each enamel color as a distinct area and identify the metal lines or borders between areas. Mark any sections that should remain as visible plated metal. Small or isolated color zones require product-specific review rather than reliance on a universal artwork rule.

Can a PDF or hand-drawn sketch be used if vector artwork is not available?

Yes. Gairun can review usable PDFs and hand-drawn concepts as starting materials, as well as vector artwork. A sketch should still show the intended shape, content and key notes. Further 2D or 3D development may be needed before the artwork can proceed toward tooling.

How should text, logos and small details be prepared for a medal, coin or pin?

Check spelling and dates, identify fonts or outline the text, and provide the clearest original logo file available. Preserve important brand proportions and explain which small features must remain. Final detail feasibility depends on the product size, material, forming method and finish.

What artwork views are needed for attachments, moving parts or multi-component products?

Provide front and reverse views plus separate drawings for each component. Mark connection points, orientation, functional areas and movement boundaries. A rotating center or linked part should be shown both on its own and in relation to the complete product.

Continue from Design Research to Artwork Review

Browse the wider Insights hub to move between design, manufacturing, event planning and sourcing topics. Use article titles, summaries, topic labels and update information to choose guidance that matches your current design question.

If your concept is defined, compare the available formats under Custom Metal Products. For a consolidated file checklist, return to the Artwork and File Preparation Guide. Buyers who already have artwork, quantity and project specifications can also request a project-specific quotation.
